Reading Time: 2 minutes


ProMark T1000 is a successor of the most popular Partex profile printer MK9-USB. Complemented with new options, and menu with Partex article numbers, it is a perfect solution for installers and producers of control cabinets and panel boards.


  • Compact, fast and portable printer to cover most of your marker needs.
  • Easy to operate with Partex product menu.
  • Feeds, prints and cuts bulk Partex profiles and self adhesive labels.
  • Store and import marker files with a USB – PC connection.
  • Cost effective identification system for use in panel building and electrical installations.


Thermal transfer printing:
300 dpi print resolution
Printing speed:
40.0 mm/s in high speed mode
25.0 mm/s
18.5 mm/s in low speed mode
Text heights:
2, 3, 4 or 6mm Maximum rows that can be printed:
1-3 rows
Temperature range:
Operating temperature: +15ºC to +32,5ºC
Operating temperature with pre-heater: from +5ºC
Storage temperature: 5ºC to +35ºC.
To obtain the best printing result, the temperature of the profile shouldn’t be lower then +20ºC
Special Features:
High production speed
Cleans the profile before print
Built in settings for all Partex profiles
USB-2.0 connection
Partex software WinSign 6.0 is included
